7
Setting up the Product
To set up the product, follow the steps below.
1. Installing the product (See “Installing the Product” on page 7.)
2. Connecting the USB cable (See “Connecting the USB Cable” on page 8.)
3. Connecting the AC adapter (See “Connecting the AC Adapter” on page 8.)
4. Turning on the product (See “Tuning on/off the Product” on page 9.)
5. Installing the roll paper (See “Installing and Replacing the Roll Paper” on page 9.)
6. Installing the ink cartridge (See “Installing and Replacing the Ink Cartridge” on page 10.)
7. Operation check with test print (See “Test Printing” on page 12.)
Installing the Product
When installing the product, make sure of the following:
❏ When carrying the product, lift the product holding the indents on both lower sides of the
product.
❏ Leave enough space around the product to open the covers, the ASF tray, and the pocket
guide.
❏ Do not place the product near any magnetic fields to avoid decreasing the MICR
recognition rate. Especially, when you install the product near a display device, check the
recognition rate of the MICR reader.
❏ Install the product horizontally.
❏ Make sure cords and foreign objects are not caught in the product.
❏ Remove the shock-absorbing materials in the product and fixing tape before use.
