8
Connecting the USB Cable
Note:
Do not turn on the product before installing the necessary drivers.
1. Connect the USB cable to the USB (Type B) connector.
2. Fix the USB cable with the cable hook to prevent the USB cable from falling off.
3. Connect the USB cable to the host computer.
Connecting the AC Adapter
Follow the steps below to connect the AC adapter.
CAUTION:
Be sure to use the specified AC adapter [PS-180 (Model: M159D/M159E)]. Connection to an improper
power source may cause fire or shock.
1. Connect the AC cable to the AC adapter.
2. Connect the DC cable of the AC adapter to the power supply connector on the product.
3. Insert the AC cable plug into a socket.
To Next Page
