Specifications
dpi: dots per 25.4 mm (dots per inch)
*1: Set DIP Switches 2-3 and 2-4 for each paper type. (See Table B on page 7.)
Font Specification
* Memory switches can be set with the memory switch setting utility.
58mm paper width model 80mm paper width model
Printing method Thermal line printing
Dot density 203 dpi × 203 dpi [dots per 25.4 mm {1"}]
Printing direction Unidirectional with friction feed
Printing width 52.5 mm {2.07"}, 420 dot positions 72 mm {2.83"}, 576 dot positions
Number of characters Alphanumeric characters: 95; International characters: 48
Extended graphics: 128 × 11 pages (including user-defined page)
Printing speed
*1
Recommended liner-free label: 150 mm/s {5.9"/s} (default)
Thermal roll paper: 177 mm/s {7.0"/s} max.
Ladder bar code and 2D code: 88 mm/s {3.46"/s}
The above speed values are approximate.
Paper feed speed Approx. 150 mm/s {approx. 5.9"/s} continuous paper feed
Line spacing (default) 3.75 mm {1/6.7"}
Roll paper
(single-ply)
Width 57.5 mm ± 0.5 mm {2.26" ± 0.02"} 79.5 mm ± 0.5 mm {3.13" ± 0.02"}
Diameter Maximum outside diameter:83 mm {3.27"}
Spool Roll Paper spool diameter:Inside: 12 mm {0.47"}; Outside: 18 mm {0.71"}
Specified thermal roll
paper type
NTP058-80 NTP080-80
Recommended liner-
free label type
MS214150 MS318150
Interface
(compatible)
Serial (RS232/RS485)/Parallel (IEEE1284)/Ethernet (10/100Base-T)/
USB (Full speed)
Receive buffer 4KB/45 bytes
Cash drawer function 2 drives
Supply voltage DC + 24 V ± 7%
Temperature Operating: 5 to 45°C {41 to 113°F}
Storage: –10 to 50°C {14 to 122°F}, except for paper
Humidity Operating: Recommended liner-free label:10 to 80% RH
Thermal roll paper: 10 to 90% RH
Storage: 10 to 90% RH, except for paper
Overall dimensions 148 × 145 × 195 mm {5.83 × 5.71 × 7.68"} (H × W × D)
Weight (mass) Approx. 1.8 kg {3.96 lb}
Memory switch setting Font
58mm paper width model 80mm paper width model
Font structure Column Font structure Column
Memory switch 5-2 ON
(default)
Font A (default) 10 × 24 42 13 × 24 44
Font B 9 × 17 46 10 × 17 57
Font C 12 × 24 35 10 × 24 57
Memory switch 5-2 OFF Font A (default) 12 × 24 35 12 × 24 48
Font B 9 × 17 46 9 × 17 64
Font C 10 × 24 42 10 × 24 57
