Epson TM-U200 Series

How to connect an Epson POS printer with Ethernet Interface
http://www.beaglehardware.com/howtoethernet.html[3/4/2011 12:27:20 PM]
Type III
Type IV
Click to select
Type IV
Installation Steps for Installing Ethernet Adapter
(Type IV)
The Type IV module (UB-E02 or similar) is the latest type of Connect-It Ethernet adapter. The module can be set by
accessing it directly using a web browser or by a configuration utility. This type of module can also act as a device type
Print server to be used by more than 1 computer.
Installing and Setting the Connect-It Ethernet Adapter (Type IV)
Install the Connect-It Ethernet adapter into the Epson TM series printer
The Type IV adapter can replace the existing adapter and is held in place by 2 screws.
If changing a printer to Ethernet you must change the specific dip switch on the Epson printer to allow for the Ethernet
card.
