8 TM-U220 User’s Manual
English
8. Insert the end of the bottom paper (journal paper) into the paper
take-up spool, as shown in illustration M.
9. Insert the paper take-up spool in the printer. Be sure that the paper
is aligned with the spool’s flange, as shown in illustration N.
10. Feed the paper with the FEED button so that the paper is taken up
by the spool.
11. Close the roll paper cover and tear off the roll paper with the
manual cutter, as shown in illustration O.
Note:
Do not open the roll paper cover during printing or paper feeding.
When using the printer, be sure to cut the roll paper with the manual cutter
after paper feeding is complete.
Replacing Roll Paper
1. Open the roll paper cover by using the tab, as shown in illustration H.
2. Types B and D: Remove the used roll paper core.
3. Type A only: Remove the take-up spool, and open the unit by
using the unit open lever, as shown in illustration I; then remove
the used roll paper core.
4. Insert new roll paper. See the section “Inserting Roll Paper”.
Troubleshooting
Printing stops before all the lines are printed or the printer prints the same
line repeatedly
If the correct power supply unit is not used, the printer cannot operate
correctly. Make sure the correct power supply unit is connected to the
printer, referring to the table below:
*Multilingual means the printer model that can print any one of the following: Japanese Kanji,
Simplified Chinese, Traditional Chinese, Thai characters, or Korean characters.
No lights on the control panel
❏ Check the power supply cable connections and the power outlet.
The power supply unit that can be used with the
TM-U220 alphanumeric model (types A, B, and D)
The power supply unit that can be used with the
TM-U220 multilingual* model (types A, B, and D)
“AC adapter, C” (packed with the alphanumeric
model) or “PS-180” (option)
“PS-180” (packed with the multilingual* model)
