TITLE
TM Printer Driver
SHEET
REVISION
NO
User's Manual
1.60
NEXT
20
SHEET
19
EPSON
4.3.Special Functions
The TM printer drivers can be used to execute a variety of special non-printing functions, as indicated in the table below.
You can execute these functions by selecting the printer's special "control font" and then sending the appropriate character
code to the driver. (Note that you cannot use the control font to print normal characters.)
You can also execute these commands by issuing codes 80H above when using non-extended printer fonts (all fonts other
than those marked by "Ext." in the printer font table in Section 4.1 above). But, The TM-U675/H6000 printer doesn't
support.
Control-Font Character
Code
Function
Extended character code
(on all fonts other than
those marked "Ext.")
A Open Drawer 1 (50ms drive pulse width) 81H
B Open Drawer 1 (100ms drive pulse width) 82H
C Open Drawer 1 (150ms drive pulse width) 83H
D Open Drawer 1 (200ms drive pulse width) 84H
E Open Drawer 1 (250ms drive pulse width) 85H
a Open Drawer 2 (50ms drive pulse width) 89H
b Open Drawer 2 (100ms drive pulse width) 8AH
c Open Drawer 2 (150ms drive pulse width) 8BH
d Open Drawer 2 (200ms drive pulse width) 8CH
e Open Drawer 2 (200ms drive pulse width) 8DH
0 Set Slip paper position
-
1 Print to journal. 91H
2 Print to receipt. 92H
3 Print to journal and receipt. 93H
5 HT 95H
6 LF 96H
7 CR 97H
8 Print to front surface of Slip
-
9 Print to back surface of Slip
-
p Do not include HRI characters with bar code. 98H
q
Print HRI characters above bar code (using font A).
99H
r
Print HRI characters below bar code (using font A).
9AH
s
Print HRI characters above bar code (using font B).
9BH
t
Print HRI characters below bar code (using font B).
9CH
! Stamp on receipt. 9FH
f Cut receipt (full cut) without paper feeding.
-
F Cut receipt (full cut). 9DH
P Cut receipt (partial cut). 9EH
