FLANGE ALIGNMENT TOOLS
OPERATOR INSTRUCTION MANUAL
PAGE 14
5. It is important that the thrust
bearing is free from dirt and
corrossion and rotates freely.
6. With the use of a penatrating oil
such as WD 40 or similar. Spray
the oil between the thrust plate
and the swivel as shown opposite.
7. Ensure the thrust plate rotates
freely before using the tool to align
a ange jont.
PENETRATING OIL
SWIVEL
THRUST
PLATE
ROTATE
