Equalizer International FA4TM - Range of Application

FLANGE ALIGNMENT TOOLS
OPERATOR INSTRUCTION MANUAL
PAGE 30
6.8 RANGE OF APPLICATION
MINIMUM AND MAXIMUM FLANGE SIZES
Dimension A: must be between 93 and 228 mm (3.75” and 9”)
Dimension B: bolt-hole diameter must be 31.5 mm (1.25”) or greater
DIMENSION
A
DIMENSION
B
