Operating instructions
Channel Value Function
1 0-255 Panadjustment
2 0-255 Tiltadjustment
3 0-255 Speed(pan&tilt)
4 0-255 0-100%dimming(0:lowbrightness,255:highbrightness)
5 0-255 Red(0:lowbrightness,255:highbrightness)
6 0-255 Green(0:lowbrightness,255:highbrightness)
7 0-255 Blue(0:lowbrightness,255:highbrightness)
8 0-255 White(0:lowbrightness,255:highbrightness)
9 0-4 Blackout
5-14 Red
15-24 Green
25-34 Blue
35-44 White
45-54 Cyan
55-64 Yellow
65-74 Orange
75-84 Pink
85-94 Purple
95-104 Pastlegreen(green&white)
105-144 Pastlered(red&white)
115-124 Pastleblue(blue&white)
125-134 Pastlepink(red,blue&white)
135-144 Warmwhite(orange&white)
145-150 Blackout
151-200 Colourfade(151:slowfade,200:fastfade)
201-255 Colourchange(201:slowchange,255:fastchange)
10 0-127 SoundcontrolviacontrollerisOFF
128-255 SoundcontrolviacontrollerisON
10 channel mode:
Changing the address:
Toaccesstheaddressmenu,pressthe“MODE”buttononthefrontoftheunittoshowAddr
isdisplayed.Pressthe“ENTER”button,theunitshouldnowdisplayA001.Usethe“UP”and“DOWN”
buttonstoselectA001throughA512.Pressthe“ENTER” buttonagain,thiswillsettheaddress.

Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
