Operating instructions
DMX mode:
Operating in a DMX control mode environment gives the user the greatest exibility when it comes
to customising or creating a show. In this mode you will be able to control each individual trait of
the xture and each xture independently.
To access the DMX mode, press the “MENU” button and use the “UP” and “DOWN” buttons to show
Addr on the LED display. Now press the “ENTER” button and use the “UP” and “DOWN” buttons to
choose one of the 2/3/3/4 or 10 DMX channel modes.
Press the “ENTER” button and use the “UP” and “DOWN” buttons to set the required DMX address.
Press the “ENTER” button to conrm the setting.
To exit out of any of the above options, press the “MENU” button.
3-2 channel mode:
Channel Value Function
CH1 000-255 Red dimmer (0-100%)
CH2 000-255 Green dimmer (0-100%)
CH3 000-255 Blue dimmer (0-100%)
4 channel mode:
Channel Value Function
CH1 000-255 Red dimmer (0-100%)
CH2 000-255 Green dimmer (0-100%)
CH3 000-255 Blue dimmer (0-100%)
CH4 000-255 White dimmer (0-100%)
2 channel mode:
Channel Value Function
CH1 000-255 Master dimmer (0-100%)
CH2
000-009 No function
010-019 Red
020-029 Green
030-039 Blue
040-049 White
050-059 Yellow
060-069 Magenta
070-079 Cyan
080-089 Dark Orange
090-099 Lime Green
100-109 Salmon Pink
110-119 Turquoise
120-129 Mint Green
130-139 Orange
140-149 Lavender
150-159 Light Blue
160-169 Dark Blue
170-255 Pink
3-1 channel mode:
Channel Value Function
CH1
000-009 No function
010-050 Program 1 (4 colour fade in/out)
051-091 Program 2 (7 colour fade in/out)
092-132 Program 3 (colour fade)
133-173
Program 4
(7 colour fade in/out + colour fade)
174-214 Program 5 (4 colour change)
215-255 Program 6 (7 colour change)
CH2
000-009 No function
010-050 Sound 1 (4 colour fade in/out)
051-091 Sound 2 (7 colour fade in/out)
092-132 Sound 3 (colour fade)
133-173
Sound 4
(7 colour fade in/out + colour fade)
174-214 Sound 5 (4 colour change)
215-255 Sound 6 (7 colour change)
CH3 000-255
Speed of Programs 1-6 (slow-fast)
Sensitivity of Sound 1-6 (low-high)
