Operating instructions
10 channel mode:
Channel Value Function
CH1 000-255 Master dimmer (0-100%)
CH2
000 No function
001-255 Strobe (slow-fast)
CH3 000-255 Red dimmer (0-100%)
CH4 000-255 Green dimmer (0-100%)
CH5 000-255 Blue dimmer (0-100%)
CH6 000-255 White dimmer (0-100%)
CH7
000-009 No function
010-019 Red
020-029 Green
030-039 Blue
040-049 White
050-059 Yellow
060-069 Magenta
070-079 Cyan
080-089 Dark Orange
090-099 Lime Green
100-109 Salmon Pink
110-119 Turquoise
120-129 Mint Green
130-139 Orange
140-149 Lavender
150-159 Light Blue
160-169 Dark Blue
170-255 Pink
Channel Value Function
CH8
000-009 No function
010-050 Program 1 (4 colour fade in/out)
051-091 Program 2 (7 colour fade in/out)
092-132 Program 3 (colour fade)
133-173
Program 4
(7 colour fade in/out + colour fade)
174-214 Program 5 (4 colour change)
215-255 Program 6 (7 colour change)
CH9
000-009 No function
010-050 Sound 1 (4 colour fade in/out)
051-091 Sound 2 (7 colour fade in/out)
092-132 Sound 3 (colour fade)
133-173
Sound 4
(7 colour fade in/out + colour fade)
174-214 Sound 5 (4 colour change)
215-255 Sound 6 (7 colour change)
CH10 000-255
Speed of Programs 1-6 (slow-fast)
Sensitivity of Sound 1-6 (low-high)
Static colour mode:
To access the static colour mode press “MENU” until Stat shows on the LED display.
Now press the “ENTER” button and use the “UP” and “DOWN” buttons to select the colour required
between S 01 ~ S 17. Press the “ENTER” button to conrm.
To exit out of any of the above options, press the “MENU” button.
S 01 - Red
S 02 - Green
S 03 - Blue
S 04 - White
S 05 - Yellow
S 06 - Magenta
S 07 - Cyan
S 08 - Dark Orange
S 09 - Lime Green
S 10 - Salmon Pink
S 11 - Turquoise
S 12 - Mint Green
S 13 - Orange
S 14 - Lavender
S 15 - Light Blue
S 16 - Dark Blue
S 17 - Pink
