Operating instructions
DMX mode:
To access the DMX address mode, press the “MENU” button to show A001 on the LED display.
Press the “ENTER” button and use the “UP” and “DOWN” buttons to set the required DMX address.
Press the “ENTER” button to conrm the setting. Now use the “UP” and “DOWN” buttons to choose one
of the 3/4/6/7/8/12/13/24/25/60/61/120 or 121 DMX channel modes. Press the “ENTER” button to
conrm the setting.
To exit out of any of the above options, press the “MENU” button.
Channel Value Function
1 000-255 Red dimmer (0-100%)
2 000-255 Green dimmer (0-100%)
3 000-255 Blue dimmer (0-100%)
3 channel mode:
Channel Value Function
1 000-255 Master dimmer (0-100%)
2 000-255 Red dimmer (0-100%)
3 000-255 Green dimmer (0-100%)
4 000-255 Blue dimmer (0-100%)
4 channel mode:
Channel Value Function
1 000-255 Red dimmer (0-100%)
Section 12 000-255 Green dimmer (0-100%)
3 000-255 Blue dimmer (0-100%)
4 000-255 Red dimmer (0-100%)
Section 25 000-255 Green dimmer (0-100%)
6 000-255 Blue dimmer (0-100%)
6 channel mode:
Channel Value Function
1 000-255 Master dimmer (0-100%)
2 000-255 Red dimmer (0-100%)
Section 13 000-255 Green dimmer (0-100%)
4 000-255 Blue dimmer (0-100%)
5 000-255 Red dimmer (0-100%)
Section 26 000-255 Green dimmer (0-100%)
7 000-255 Blue dimmer (0-100%)
7 channel mode:
