Operating instructions
Channel Value Function
1 000-255 Master dimmer (0-100%)
2
000 No function
001-255 Strobe (slow-fast)
3
000-009 No function
010-019 Static colours
use channel 5 for
colour selection
020-029 Colour pulse
030-039 Colour change
040-049 Colour fade
050-059 Colour fade in and change
060-069 Effect 1
use channel 5 for
colour selection
070-079 Effect 2
080-089 Effect 3
090-099 Effect 4
100-109 Effect 5
110-119 Effect 6
120-129 Effect 7
130-139 Effect 8
140-149 Effect 9
150-159 Effect 10
160-169 Effect 11
170-179 Effect 12
180-189 Effect 13
190-199 Effect 14
200-209 Effect 1-14
210-219 Sound mode 1
use channel 5 for
sensitivity
220-229 Sound mode 2
230-255 Sound mode 3
4 000-255 Speed (slow-fast)
5 000-255 Colour selection/sensitivity (low-high)
6 000-255 Red dimmer (0-100%)
7 000-255 Green dimmer (0-100%)
8 000-255 Blue dimmer (0-100%)
8 channel mode:
