Equinox Systems PIXELpoint Batten - DMX Channel Mode Details (Continued); 12, 13, 24, and 25 Channel Mode Details

www.prolight.co.uk PIXELpoint Batten User Manual
9
Operating instructions
Channel Value Function
1 000-255 Red dimmer (0-100%)
Section 12 000-255 Green dimmer (0-100%)
3 000-255 Blue dimmer (0-100%)
4 000-255 Red dimmer (0-100%)
Section 25 000-255 Green dimmer (0-100%)
6 000-255 Blue dimmer (0-100%)
7 000-255 Red dimmer (0-100%)
Section 38 000-255 Green dimmer (0-100%)
9 000-255 Blue dimmer (0-100%)
10 000-255 Red dimmer (0-100%)
Section 411 000-255 Green dimmer (0-100%)
12 000-255 Blue dimmer (0-100%)
12 channel mode:
Channel Value Function
1 000-255 Master dimmer (0-100%)
2 000-255 Red dimmer (0-100%)
Section 13 000-255 Green dimmer (0-100%)
4 000-255 Blue dimmer (0-100%)
5 000-255 Red dimmer (0-100%)
Section 26 000-255 Green dimmer (0-100%)
7 000-255 Blue dimmer (0-100%)
8 000-255 Red dimmer (0-100%)
Section 39 000-255 Green dimmer (0-100%)
10 000-255 Blue dimmer (0-100%)
11 000-255 Red dimmer (0-100%)
Section 412 000-255 Green dimmer (0-100%)
13 000-255 Blue dimmer (0-100%)
13 channel mode:
Channel Value Function
1 000-255 Red dimmer (0-100%)
Section 12 000-255 Green dimmer (0-100%)
3 000-255 Blue dimmer (0-100%)
4 000-255 Red dimmer (0-100%)
Section 25 000-255 Green dimmer (0-100%)
6 000-255 Blue dimmer (0-100%)
... ...
...
...
19 000-255 Red dimmer (0-100%)
Section 720 000-255 Green dimmer (0-100%)
21 000-255 Blue dimmer (0-100%)
22 000-255 Red dimmer (0-100%)
Section 823 000-255 Green dimmer (0-100%)
24 000-255 Blue dimmer (0-100%)
24 channel mode:
25 channel mode:
Channel Value Function
1 000-255 Master dimmer (0-100%)
2 000-255 Red dimmer (0-100%)
Section 13 000-255 Green dimmer (0-100%)
4 000-255 Blue dimmer (0-100%)
5 000-255 Red dimmer (0-100%)
Section 26 000-255 Green dimmer (0-100%)
7 000-255 Blue dimmer (0-100%)
... ...
...
...
20 000-255 Red dimmer (0-100%)
Section 721 000-255 Green dimmer (0-100%)
22 000-255 Blue dimmer (0-100%)
23 000-255 Red dimmer (0-100%)
Section 824 000-255 Green dimmer (0-100%)
25 000-255 Blue dimmer (0-100%)
