Operating instructions
60 channel mode:
Channel Value Function
1 000-255 Red dimmer (0-100%)
Pixel
1 & 2
2 000-255 Green dimmer (0-100%)
3 000-255 Blue dimmer (0-100%)
4 000-255 Red dimmer (0-100%)
Pixel
3 & 4
5 000-255 Green dimmer (0-100%)
6 000-255 Blue dimmer (0-100%)
... ...
...
...
55 000-255 Red dimmer (0-100%)
Pixel
37 & 38
56 000-255 Green dimmer (0-100%)
57 000-255 Blue dimmer (0-100%)
58 000-255 Red dimmer (0-100%)
Pixel
39 & 40
59 000-255 Green dimmer (0-100%)
60 000-255 Blue dimmer (0-100%)
61 channel mode:
Channel Value Function
1 000-255 Master dimmer (0-100%)
2 000-255 Red dimmer (0-100%)
Pixel
1 & 2
3 000-255 Green dimmer (0-100%)
4 000-255 Blue dimmer (0-100%)
5 000-255 Red dimmer (0-100%)
Pixel
3 & 4
6 000-255 Green dimmer (0-100%)
7 000-255 Blue dimmer (0-100%)
... ...
...
...
56 000-255 Red dimmer (0-100%)
Pixel
37 & 38
57 000-255 Green dimmer (0-100%)
58 000-255 Blue dimmer (0-100%)
59 000-255 Red dimmer (0-100%)
Pixel
39 & 40
60 000-255 Green dimmer (0-100%)
61 000-255 Blue dimmer (0-100%)
120 channel mode:
Channel Value Function
1 000-255 Red dimmer (0-100%)
Pixel 12 000-255 Green dimmer (0-100%)
3 000-255 Blue dimmer (0-100%)
4 000-255 Red dimmer (0-100%)
Pixel 25 000-255 Green dimmer (0-100%)
6 000-255 Blue dimmer (0-100%)
... ...
...
...
115 000-255 Red dimmer (0-100%)
Pixel 39116 000-255 Green dimmer (0-100%)
117 000-255 Blue dimmer (0-100%)
118 000-255 Red dimmer (0-100%)
Pixel 40119 000-255 Green dimmer (0-100%)
120 000-255 Blue dimmer (0-100%)
121 channel mode:
Channel Value Function
1 000-255 Master dimmer (0-100%)
2 000-255 Red dimmer (0-100%)
Pixel 13 000-255 Green dimmer (0-100%)
4 000-255 Blue dimmer (0-100%)
5 000-255 Red dimmer (0-100%)
Pixel 26 000-255 Green dimmer (0-100%)
7 000-255 Blue dimmer (0-100%)
... ...
...
...
116 000-255 Red dimmer (0-100%)
Pixel 39117 000-255 Green dimmer (0-100%)
118 000-255 Blue dimmer (0-100%)
119 000-255 Red dimmer (0-100%)
Pixel 40120 000-255 Green dimmer (0-100%)
121 000-255 Blue dimmer (0-100%)
Colour mix mode:
To access the static colour mode press “MENU” until r000 shows on the LED display.
Now use the “UP” and “DOWN” buttons to select the brightness between r.000 ~ r.255. Press the
“ENTER” button and repeat for green (g) and blue (b).
Value: 000 - 255 (000 = low brightness, 255 = high brightness)
