Multiple xture power linking
Power linking:
This xture provides power linking via the power output on the rear allowing multiple units to be
connected together. The maximum number of xtures that can be connected is 16 xtures @ 240V
or 8 xtures @ 120V (including the rst xture). After the maximum number of xtures are
connected a new power run will need to be started.
Please note: Caution should be used when power linking other xtures to the SpectraPix Batten as the
power consumption of other xtures will vary. Fixtures tted with lamps often require 2/3 times more
current on startup, these may require their own power source.
