Technical specications
01-LCDdisplay
02-Menubutton
03-Upbutton
04-Downbutton
05-Enterbutton
06-3-pinDMXinput
07-3-pinDMXouput
08-PowerCONinput
09-PowerCONinput
10-On/offswitch
11-FuseF3A250V
12-Rubberfeet
13-Vents
14-Omegaclampmounts
15-Safetybondpoint
02
03
04
05
06
13 1314 14 14 1415
07 08 09 10 11
01
Inthebox:1 x xture,
1 x power cable,
1 x user manual &
2 x omega clamps
12 12
