Equinox Systems Swing Batten - Master;Slave Mode

www.prolight.co.uk Swing Batten User Manual
8
Operating instructions
Master/slave mode:
Tosetthemasterunit,pressthe“MENU”buttononthefrontofthemasterunittoshowSLNd onthe
LEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochooseNast.
Pressthe“ENTER”buttontoconrmthesetting.Thenselectyourdesiredprogram(soundactive,DMX
oroneofthebuilt-inprograms).
Tosettheotherunitsinslavemode,pressthe“MENU”buttononthefrontoftheunittoshowSLNd
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
eitherSL1(Slave1)orSL2(Slave2).Pressthe“ENTER”buttontoconrmthesetting.Theunitwill
nowruninsequencewiththemasterunit.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
PleaseensurethatallslaveunitsaresettothesameDMXchannelmodeasthemasterunit.
Show mode (built-in programs):
Toaccesstheshowmodes,pressthe“MENU”buttononthefrontoftheunittoshowShNd
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoosethe
showyourequirefromSh 0~Sh 8.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.

Sound active mode:
Toaccessthesoundactivemode,pressthe“MENU”buttononthefrontoftheunittoshowSoUn
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstosetthe
soundmodeonoroff.Pressthe“ENTER”buttontoconrmthesetting.
Toadjustthesoundsensitivity,pressthe“MENU”buttononthefrontoftheunittoshowSens
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstosetthe
soundsensitivity0~100.Pressthe“ENTER”buttontoconrmthesetting.
Value: 0 - 100 (0 = low sensitivity, 100 = high sensitivity)
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
