Equinox Systems Swing Batten - Page 6

www.prolight.co.uk Swing Batten User Manual
6
Operating instructions
6 channel mode:
Channel Value Function
CH1 000-255 Masterdimmer(0-100%)
CH2
000-007 Nofunction
008-255 Strobe(slow-fast)
CH3
000-007 Nofunction
008-049 Show1
050-091 Show2
092-133 Show3
134-175 Show4
176-217 Show5
218-247 Show6
248-255 Soundactive
CH4 000-255 Showmodespeed(slow-fast)
CH5
000-005 Nofunction
006-009 R
010-013 G
014-017 B
018-021 W
022-025 RG
026-029 RB
030-033 RW
034-037 GB
038-041 GW
042-045 BW
046-049 RGB
050-053 RGW
054-057 RBW
058-061 GBW
062-063 RGBW
064-079 Colourchase1
080-095 Colourchase2
096-111 Colourchase3
112-127 Colourchase4
128-143 Colourchase5
144-159 Colourchase6
160-175 Colourchase7
176-191 Colourchase8
192-207 Colourchase9
208-223 Colourchase10
224-239 Colourchase11
240-255 Colourchase12
CH6 000-255 Colourchasespeed(slow-fast)
12 channel mode:
Channel Value Function
CH1 000-255 Tilt(0°-270°)
CH2 000-255 Tiltmovementspeed
CH3 000-255 Masterdimmer(0-100%)
CH4
000-007 Nofunction
008-255 Strobe(slow-fast)
CH5
000-008 Nofunction
009-024 LED1-R
025-041 LED1-G
042-057 LED1-B
058-074 LED1-W
075-090 LED1-RG
091-107 LED1-RB
108-123 LED1-RW
124-140 LED1-GB
141-156 LED1-GW
157-173 LED1-BW
174-189 LED1-RGB
190-206 LED1-RGW
207-222 LED1-RBW
223-239 LED1-GBW
240-255 LED1-RGBW
CH6 - LED2(usevaluesfromCH5)
CH7 - LED3(usevaluesfromCH5)
CH8 - LED4(usevaluesfromCH5)
CH9 - LED5(usevaluesfromCH5)
CH10 - LED6(usevaluesfromCH5)
CH11 - LED7(usevaluesfromCH5)
CH12 - LED8(usevaluesfromCH5)
