ergoline ergometrics er 800S - Installation; Installation Features and Connections

Version: 05/02 1 er800S Operation Manual
Art-Nr: 475.051
Operation Manual
Ergometer
Type er800S
Chapter 1: Installation
1.1 Features and Connections
1 power connector, fuse and main power switch
2 clamp handle for seat adjustment
3 clamp handle for handlebar height adjustment
4 clamp handle for handlebar angle adjustment
5 transport casters
6 control panel with keypad and LED displays
7 leveling feet for optimal stability
1
2
46
3
5
7
