Checking the system
20
4.3 LEDs on the base stations
Figure 3 shows the position of the two base station LEDs:
Fig. 4 Base station LEDs
LED Normally When On Meaning Required action when on
1 On Green Power on None, normal situation
2 Off Red Message
received but not
read yet
Read the message with CSM if
available.
Note that the system may continue
to function properly if only LED2
is on (red).
3 - 6 Off Red Radio exchange
error
Try resetting the radio exchange:
switch the radio exchange off,
waiting half a minute and switch-
ing it on again.
If this does not fix the problem,
please contact your supplier.
Table 1 Meaning of radio exchange LEDs
Front view
LED1
LED2
018
