Using CSM
28
Fig. 5 PC connector at bottom side radio exchange
3. Start the CSM software.
4. Set the right COM port and baud rate for communication with the cordless
system. Supported baud rates are 2400, 4800 and 9600 baud.
5. Establish the connection to the cordless system.
6.3 Working with CSM
To work with CSM, use both the functions in the menu bar and the windows.
For example, if you want to subscribe a cordless phone first establish a
connection, then select the window ‘Cordless Phones’ and finally choose the
option ‘Subscribe Cordless Phone’ from the ‘Cordless Phone’ menu.
For more information, please see the help file of CSM.
Tip
Instead of using the menu bar, you can often use the right mouse button too.
Clicking on the right mouse button often displays a pop-up menu.
Note
CSM has password-protected functions. These are special functions for your
supplier (distributor).
l 0
016
PC connector
(RS232)
