Preparing for remote maintenance
34
2. Disconnect the PC cable from the cordless system.
3. Connect the PC with a PC cable to the modem, see figure 7.
Fig. 7 PC initialising system side mode
4. Switch on the modem.
5. Initialise the system side modem with CSM in the ‘Too ls’ menu with the
option ‘Initialise System Side Modem’:
a. Select the COM port of the modem.
b. Set the baud rate of the cordless system.
c. In case of non-standard modems, you can change the AT commands
that will be sent to the modem by clicking the ‘Advanced’ button (see
the CSM help file).
6. Disconnect the PC cable from the modem.
7. Connect the modem to the cordless system, with the Modem shell adapter
and the PC cable (see figure 6).
8. Connect the modem to an analogue telephone line.
9. Check that the modem is on.
The cordless system is now ready for remote maintenance.
Installing the CSM side modem
1. If you use an external modem, connect the CSM side modem to COM1
or COM2 of the remote PC with the PC modem cable.
2. Make sure that CSM is installed on the remote PC.
PC with CSM
PC modem cable
System side
modem
027
