Radio Configurations, RBS 2106 and RBS 2206
Table 16 1 +1 + 2 configurations with CDU-G
Cell
TMA
CDU
TMA Antenna
1
1
TX / RX1
1
TX / RX A
2
TX / RX1
3
TX / RXA
2 1
RX / RX2
2
TX / RXA
2
TX / RX2
4
RXB
3 3
TX / RX1
5
TX / RXA
3
TX / RX2
6
TX / RXB
Table 17 2 x 6 configurations with CDU-F
Cell CDU
TMA Antenna
No. / Connector
No. (TMA config. only)
1
1 / TX / RX
1
TX / RXA
1/RX
2 RXB
2
3 / TX / RX
5
TX / RXA
3/RX
6
RXB
Table 18 2 x 6 configurations with CDU-G
Cell CDU ASU Connector
TMA Antenna
No. / Connector (Co-siting only)
No. (TMA config.
only)
1
1 / TX / RX1
1 1
TX / RXA
1 / TX / RX2
2 2
TX / RXB
2
3 / TX / RX1
5 5
TX / RXA
3 / TX / RX2
6 6
TX / RXB
Table 19 3 x 4 configurations with CDU-F
Cell CDU
TMA Antenna
No. / Connector No. (TMA config. only)
1
1 / TX / RX
1
TX / RXA
1/RX
2
RXB
2
2 / TX / RX
4
RXB
2/RX
3
TX / RXA
3
3 / TX / RX
6 RXB
3/RX
5
TX / RXA
68 (485)
