Radio Configurations, RBS 2106 and RBS 2206
CDU-F Configurations for GSM 900 and GSM 1800
Table 29 Dual band configurations with CDU-F in a fully- or partly-equipped cabinet
SCC
Configuration TMA Number of
Antennas
Allowed Number of dTRUs
1x4|1x8
F9de_2.4 | F18d_2.8 No | No (2) | (2) (0..2) | (0..2)
F9det_2.4 | F18dt_2.8 M|M (2) | (2) (0..2) | (0..4)
1x8|1x4 F9de_2.8 | F18d_2.4 No | No (2) | (2) (0..4) | (0..2)
F9det_2.8 | F18dt_2.4 M|M (2) | (2) (0..4) | (0..2)
1x4|2x4 F9de_2.4 | 2 x F18d_2.4 No | No (2) | (2) (2) (0..2) | (0..2) (0..2)
F9det_2.4 | 2 x F18dt_2.4 M|M (2) | (2) (2) (0..2) | (0..2) (0..2)
2x4|1x4 2 x F9de_2.4 | F18d_2.4 No | No (2) (2) | (2) (0..2) (0..2) | (0..2)
2 x F9det_2.4 | F18dt_2.4 M|M (2) (2) | (2) (0..2) (0..2) | (0..2)
M = Mandatory
There are two options for placing the equipment in the cabinet:
GSM 900 on the left-hand side/GSM 1800 on the right-hand side, or the
other way round.
Table 30 Dual band configurations with CDU-F in a partly-equipped cabinet only
SCC Configuration TMA Number of
Antennas
Allowed Number of dTRUs
1x4|1x4 F9de_2.4 | F18d_2.4 No | No (2) | (2) (0..2) (0) | (0..2)
F9det_2.4 | F18dt_2.4 M|M (2) | (2) (0..2) (0) | (0..2)
M = Mandatory
There are two options for placing the equipment in the cabinet:
GSM 900 on the left-hand side/GSM 1800 on the right-hand side, or the
other way round. In each case the middle positions are not used.
CDU-G Configurations for GSM 900 and GSM 1800
Table 31 Dual band configurations, CDU-G with hybrid in a fully- or partly-equipped
cabinet
SCC Configuration TMA Number of
Antennas
Allowed Number of dTRUs
1x8|1x4 G9deh_4.8 | G18dh_2.4 No | No (4) | (2) (0..4) | (0..2)
G9deht_4.8 | G18dht_2.4 M|M (4) | (2) (0..4) | (0..2)
1x4|1x8 G9deh_2.4 | G18dh_4.8 No | No (2) | (4) (0..2) | (0..4)
G9deht_2.4 | G18dht_4.8 M|M (2) | (4) (0..2) | (0..4)
2x4|1x4 2 x G9deh_2.4 | G18dh_2.4 No | No (2) (2) | (2) (0..2) (0..2) | (0..2)
2 x G9deht_2.4 | G18dht_2.4 M|M (2) (2) | (2) (0..2) (0..2) | (0..2)
1x4|2x4 G9deh_2.4 | 2 x G18dh_2.4 No | No (2) | (2) (2) (0..2) | (0..2) (0..2)
G9deht_2.4 | 2 x G18dht_2.4 M|M (2) | (2) (2) (0..2) | (0..2) (0..2)
M = Mandatory
