ERVOR G05 - Page 41

Page 41
Notice G05 - 3 590 503
Issue: 11/2011 - Rev.A
ERVOR (SCA) - 6, Rue Désiré Granet - Z.I. du Val d'Argent - 95100 ARGENTEUIL FRANCE
 (33) 01 34 11 50 00  (33) 01 34 11 50 10
Web : www.ervor.com - Email : info@ervor.com
ITEM DESCRIPTION Qty DRAWING REFERENCE
NUMBER
1 AIR FAN SAFETY GRILL 1 PG0542D3 3 945 005
2 COOLING COIL SHOCK ABSORBER SET 1 P*G105109 8 960 007
COOLING COIL WITH CONNECTORS 1 ------------- 8 141 541
(
Standard - Bureau Veritas
)
COOLING COIL WITH CONNECTORS 1 ------------- 8 141 547
(
Llo
y
d’s Re
g
ister
)
4 AIR FAN 1 PT5033D6 1 050 002
5 SET OF GASKETS 1 P*G0575 8 970 008
6 SIMPLE BEARING 1 PG056bisT26 3 936 017
7 BALL BEARING 2 PG056306 7 520 020
8 PISTON SPINDLE 1 PG0531Q51 3 925 015
8A CIRCPLIPS 2 PC3QI 7 430 003
9 ECCENTRIC SHAFT WITH BALANCE MASS 1 P*G0530 8 920 001
10+30 SET OF PISTON RINGS 1 P*G05106 8 970 089
11 1st STAGE COMPRESSION CAP 1 PG0511T21 3 934 004
12+25 SET OF VALVES 1 P*G0511 8 970 069
13 L.P. CYLINDER HEAD ASSEMBLY WITH 1st STAGE VALVES 1 P*G0519 8 932 002
14 INTAKE PIPE 1 PG05PAT18 1 934 007
15 INTAKE FILTER 1 PCG04FIQ1019 7 200 001
16 OIL DISCHARGE PLUG 1 PCBMD001300 7 603 017
17 OIL PLUG 1 PCTPS20 7 603 007
18 OIL PIPE ASSEMBLY 1 P*PIPEHUILE 8 934 000
L.P. CYLINDER 1st STAGE - Standard 1 PG055D4 3 931 003
L.P. CYLINDER 1st STAGE - Bureau Veritas 1 ------------- 3 931 004
L.P. CYLINDER 1st STAGE - Lloyd’s Register 1 ------------- 3 931 021
20 BEARING 1 PG056T29 3 936 011
20A CIRCLIPS 1 PC72I 7 430 008
21 SPACER 1 PG0532Q58 3 921 001
22 SNIFTING VALVE CAP 1 PG059T20 1 941 006
23 SNIFTING VALVE 1 PG308T19 3 934 019
H.P. CYLINDER 2nd STAGE - Standard 1 PG054D5 3 931 006
H.P. CYLINDER 2nd STAGE - Bureau Veritas 1 ------------- 3 931 005
H.P. CYLINDER 2nd STAGE - Lloyd’s Register ------------- 3 931 022
26 H.P. CYLINDER HEAD ASSEMBLY WITH 2nd STAGE VALVES 1 P*G0514 8 932 003
27 2nd STAGE H.P. COLLECTOR 1 PG0518T23 3 934 009
28 CASING 1 PG057U169 3 930 008
29 CONNECTING ROD WITH OIL PROJECTOR 1 P*T502 8 960 004
31 MONOBLOC PISTON WITH RINGS 1 P*G051 8 923 002
32 WOODRUFF KEY 2 PTRQ10082 7 440 001
33 COOLING COIL TUBE 1
PCBOB20x27x115
7 602 009
34 GRATING LUG : include with air fan safety grill item.1 1 PG05Q42 1 942 002
35 SPACER (type double cooler) 2 -------------- 3 450 013
36 OIL LEVEL SWITCH 1 -------------- 7 710 040
3
19
24
