Page 28
Notice G05 - 3 590 503
Issue: 11/2011 - Rev.A
ERVOR (SCA) - 6, Rue Désiré Granet - Z.I. du Val d'Argent - 95100 ARGENTEUIL FRANCE
(33) 01 34 11 50 00 (33) 01 34 11 50 10
Web : www.ervor.com - Email : info@ervor.com
11 - B - CYLINDER HEADS & VALVES
The G05 compressor's intake and compression valves are made of annular discs which run
automatically.
Good water-tightness is necessary between the discs and their seats (avoid running the compressor
with clogged valves, with carbon deposits, oil carbon or more importantly, with broken valves).
In order to limit the number of parts, ERVOR use two types valves.
11 - B - 1 - COMPOSITION OF VALVES ON CYLINDER HEADS
1ST STAGE CYLINDER HEAD LOW PRESSURE
- INTAKE VALVE .......................................................... Ø 30 Qty 2
- COMPRESSION VALVE ............................................ Ø 30 Qty 2
2ND STAGE CYLINDER HEAD HIGH PRESSURE
- INTAKE VALVE .......................................................... Ø 30 Qty 1
- COMPRESSION VALVE ............................................ Ø 30 Qty 1
