ESAB A6 VEC User Manual

-- 3 6 --
dgb3r11a
C = Component designation in the circuit diagram
Item
no.
Qty Ordering no. Denomination Notes C
0443 393 001 VEC--motor with gear
7 0147 576 002 Worm wheel 36 coggs 74:1
0147 577 002 Worm wheel 38 coggs 156:1
0155 041 002 Worm wheel
0147 578 002 Worm wheel 38 coggs 312:1
0147 579 002 Worm wheel 82 coggs 672:1
10 1 2213 020--06 Ball bearing SKF 6005
11 1 0145 732 001 Bearing housing
12 1 2216 010--08 Sealing ring
13 1 2213 019--05 Ball bearing
14 1 0145 730 001 Shaft square neck
0146 501 001 Shaft conical neck
15 1 0145 731 001 Ring
18 1 2154 012--06 Locking washer
19 1 2154 013--06 Nut
20 1 0190 788 101 Tube end plug
22 1 0145 784 001 Cover plate
23 2 2152 013--32 O-- ring
24 1 0145 243 001 Gear housing
25 1 2216 009--44 Sealing ring
26 1 0190 531 202 Ball bearing
27 1 2213 077--13 Needle bearing
28 0147 576 001 Worm screw 4 input 74:1
0147 577 001 Worm screw 2 input 156:1
0147 578 001 Worm screw 1 input 312:1
0147 579 001 Worm screw 1 input 672:1
29 1 0147 423 001 Woodruf f key
30 1 0144 703 001 Ring
31 1 0147 020 002 Gear wheel
35 1 0145 187 001 Bearing bracket
37 1 0147 020 007 Rotor 42 V 1000 r/min, 75 V 2000 r/min
0147 020 008 Rotor 42 V 1500 r/min, 75 V 3000 r/min
0147 020 006 Rotor 42 V 2000 r/min, 75 V 4000 r/min
0147 020 004 Rotor 42 V 3000 r/min, 75 V 6000 r/min
0147 020 005 Rotor 42 V 4000 r/min, 75 V 8000 r/min
0147 020 009 Rotor 42 V 8000 r/min
53 1 2157 015--63 Key
