dgb3r11a
C = Component designation in the circuit diagram
Item
no.
Qty Ordering no. Denomination Notes C
VEC--motor with gear
35 1 0145 187 001 Bearing bracket
36 0190 725 201 Ball bearing
37 1 0147 020 007 Rotor 42 V 1000 r/min, 75 V 2000 r/min
0147 020 008 Rotor 42 V 1500 r/min, 75 V 3000 r/min
0147 020 006 Rotor 42 V 2000 r/min, 75 V 4000 r/min
0147 020 004 Rotor 42 V 3000 r/min, 75 V 6000 r/min
0147 020 005 Rotor 42 V 4000 r/min, 75 V 8000 r/min
0147 020 009 Rotor 42 V 8000 r/min
38 1 2213 020--33 Ball bearing SKF 6000Z
39 1 0147 020 001 Field coil
40 2 4395 017--01 Carbon brush
41 1 0147 020 003 Brush carrier
42 1 2195 047--07 Washer
45 1 0190 455 481 Screw
48 1 0145 186 001 Motor housing
49 1 0146 866 001 Insulating plate
50 1 0146 869 001 Cover plate
51 1 0148 213 001 Terminal block
52 1 0148 561 001 Plug
54 1 0146 867 001 Cover plate
