-- 4 2 --
dgb3r11a
C = Component designation in the circuit diagram
Item
no.
Qty Ordering no. Denomination Notes C
V E C -- m o t o r w i t h d i s e n --
gageable gear
2 1 0154 127 001 Cover plate
3 1 0111 185--07 Hose nipple
4 1 0154 126 001 Flange
5 2 0155 035 001 Diaphragm
6 1 0155 033 001 Washer
7 1 0155 090 001 Eccentric
8 1 0190 240 104 Bearing bushing
9 1 0155 089 001 Plunger
10 1 0155 091 001 Lever
12 1 0155 093 001 Cover plate
13 1 2188 1 10--03 Ball handle
14 1 0155 029 001 Cover plate
15 1 0192 546 807 Ball bearing
16 1 0155 036 001 Clutch
17 1 0155 032 001 Washer
18 1 0155 030 001 Clutch wheel
19 0155 040 002 Worm wheel 36 coggs 74:1
0155 042 002 Worm wheel 38 coggs 156:1
0155 043 002 Worm wheel 82 coggs 672:1
20 1 0155 028 001 Sleeve
21 1 0155 034 001 Nut
22 1 2213 020--08 Ball bearing
23 1 0155 038 001 Shaft
0155 039 001 Shaft
24 1 0192 190 023 Compression spring
25 1 0190 463 105 Ball bearing
26 1 0155 031 001 Nut
27 1 0155 037 001 Bearing housing
