ESAB Aristo Mig 3001i User Manual

S0740 800 196/E101019/P76
- 74 -
ca41i1
FAULT-TRACING
Try these recommended checks and inspections before sending for an authorized service
technician.
Type of fault Corrective action
No arc S Check that the mains power supply switch is turned on.
S Check that the welding and return cables are correctly connected.
S Check that the correct current value is set.
S Check the mains power supply fuses.
The welding current is
interrupted during
welding.
S Check whether the overloading protection has tripped (indicated in the
control panel).
S Check the mains power supply fuses.
The overloading
protection trips
frequently.
S Check to see whether the dust filter is clogged.
S Make sure that you are not exceeding the rated data for the power
source (i.e. that the unit is not being overloaded).
Poor welding perform
ance
S Check that the welding and return cables are correctly connected.
S Check that the correct current value is set.
S Check that the correct wire or electrode is used.
S Check the mains power supply fuses.
SPARE PARTS
The spare parts list is published in a separate document that can be downloaded from the
internet: www.esab.com
Product Filename
Mig 3001i
0459 839 031
Tig 3001i 0459 839 033

ESAB Aristo Mig 3001i Specifications

General

Output Current Range	30 - 300 A
Output Current	300 A
Duty Cycle	60 % at 300 A
Cooling Type	Forced air
Wire Diameter Range	0.8 - 1.2 mm
Protection Class	IP23
Input Voltage	3 x 400 V
