3 TECHNICAL DATA
0463 431 101
- 8 -
© ESAB AB 2017
3 TECHNICAL DATA
Mig 4004i Pulse / Mig 4004i Pulse WeldCloud™
Mains voltage 380-460V, ±10%, 3~ 50/60 Hz
Mains supply S
scmin
5.8 MVA
Primary current I
max
28 A
No-load power 57 W
Setting range (DC)
MIG/MAG 16 A / 14.8 V - 400 A / 34 V
MMA 16 A / 20.6 V - 400 A / 36 V
TIG 4 A / 10.2 V - 400 A / 26 V
Permissible load at MIG/MAG
60 % duty cycle 400 A / 34.0 V
100% duty cycle 300 A / 29.0 V
Permissible load at MMA
60 % duty cycle 400 A / 36.0 V
100% duty cycle 300 A / 32.0 V
Permissible load at TIG
60 % duty cycle 400 A / 26.0 V
100% duty cycle 300 A / 22.0 V
Power factor at maximum current 0.95
Efficiency at maximum current 89.5 %
Open circuit voltage 55 V
Operating temperature -10 to 40°C (14 to 104°F)
Transport temperature -20 to 55°C (-4 to 131°F)
Constant sound pressure when
idling
<70 dB (A)
Dimensions l×w×h Mig 4004i Pulse:
613 × 257 × 445 mm (24.0 × 10.1 × 17.5 in.)
Mig 4004i Pulse WeldCloud™:
613 × 257 × 517 mm (24.0 × 10.1 × 20.3 in.)
Weight Mig 4004i Pulse: 45 kg (99.2 lb)
Mig 4004i Pulse WeldCloud™: 50 kg (110lb)
Insulation class H
Enclosure class IP23
Application classification
Mains supply, S
sc min
Minimum short circuit power on the network in accordance with IEC 61000-3-12.
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or
cut at a certain load without overloading. The duty cycle is valid for 40°C/104°F, or below.
