Feed L304
R0459 508/E110203/P24
-19-
bm38whn1
HD = Heavy Duty
Item Ordering no. Denomination Notes
HN1 0455 072 002
0456 615 001
Intermediate nozzle
Intermediate nozzle
For Fe, Ss & cored wire
For Al Wire
HN2 0469 837 880
0469 837 881
Outlet nozzle
Outlet nozzle
For Fe, Ss & cored wire, Ø 2.0 mm steel for 0.6-1.6 mm
For Al wire, Ø 2.0 mm plastic for 0.8-1.6 mm
HN3 0191 496 114 Woodruff wedge
HN4 0459 440 001 Motor gear euro
HN5 Washer Ø 16/5x1
HN6 Screw M4x12
HN7 Screw M6x12
HN8 Washer Ø 12/6.4x1.5
HN9 0469 838 001 Cover
HN10 0458 722 880 Axle and Nut
HN11 0369 557 001 Feed roller For Fe, Ss & cored wire, Ø 0.6 & 0.8 mm, V groove
0369 557 002 Feed roller For Fe, Ss & cored wire, Ø 0.8 & 1.0 mm, V groove
0369 557 003 Feed roller For Fe, Ss & cored wire, Ø 1.0 & 1.2 mm, V groove
0369 557 004 Feed roller For Cored wire, Ø 1.0 & 1.2 mm, V-Knurled groove
0369 557 013 Feed roller For Cored wire, Ø 1.4 & 1.6 mm, V-Knurled groove
0369 557 011 Feed roller For Al wire, Ø 0.8 & 0.9 mm, U groove
0369 557 006 Feed roller For Al wire, Ø 1.0 & 1.2 mm, U groove
HN12 0459 441 880 Gear adapter
HN13 0455 049 001 Inlet nozzle
HN14 0455 906 001 Spacer sleeve
HN15 0455 907 001 Pressure roller Flat
HN16 0215 702 708 Locking washer
HN17 0459 518 001 Axel pressure roll
HN18 Nut M10
HN19 0458 748 002 Insulating washer
HN20 0458 748 001 Insulating bushing
HN21 0156 602 001
0332 318 001
Inlet nozzle
Inlet nozzle (HD)
For Fe, Ss, Al & Cored wire, Ø 2 mm plastic for 0.6-1.6 mm
For Fe, Ss & Cored wire, Ø 2.4 mm steel for 1.2-2.0 mm
Welding with aluminium wire
In order to weld with aluminium wire, proper rollers, nozzles and liners for aluminium wire MUST be
used, It is recommended to use 3 m long welding gun for aluminium wire, equipped with appropriate
wear parts.
