Dispose of electronic equipment at the recycling facility!
In observance of European Directive 2002/96/EC on Waste Electrical and Electronic
Equipment and its implementation in accordance with national law, electrical and/or
electronic equipment that has reached the end of its life must be disposed of at a
recycling facility.
As the person responsible for the equipment, it is your responsibility to obtain
information on approved collection stations.
For further information contact the nearest ESAB dealer.
3 INTRODUCTION
The Feed L302 with control panel M08 and Feed L304 with control panel M09 wire
feed units are intended for MIG/MAG welding with the Mig L405 power source.
They come in different variants, see page 16.
The feed units can be used together with wire on ESAB's MarathonPact, or on wire
bobbin Ø 300 mm.
They can be installed either at the power source, suspended above the workplace,
on a support arm or on the floor with or without wheel set.
ESAB's accessories for the product can be found on page 21 .
3.1 Equipment
The wire feed units are supplied with an instruction manual and stickers.
4 TECHNICAL DATA
Feed L302 Feed L304
Power supply 42 V 50-60 Hz 42 V 50-60 Hz
Power requirement 150 VA 150 VA
Motor current I
max
3.5 A 3.5 A
Settings data
Wire feed speed
Burnback time
Spot welding time
1.5-22.0 m/min
0-0.7 s
-
1.5-22.0 m/min
0-0.7 s
0.2-5 s
Gun connection EURO EURO
Max. diameter wire bobbin 300 mm 300 mm
Wire dimension
Fe
Ss
Al
Cored wire
0.6-1.2 mm
0.6-1.2 mm
1.0-1.2 mm
0.8-1.2 mm
0.6-1.6 mm
0.6-1.2 mm
1.0-1.6 mm
0.8-1.6 mm
Weight 12.6 kg 13.2 kg
Dimensions (l x b x h) 569 x 259 x 355 mm 569 x 259 x 355 mm
Operating temperature -10 to + 40°C -10 to + 40°C
Shielding gas
max pressure
Gases for MIG/MAG welding
5 bar
Gases for MIG/MAG welding
5 bar
