ESAB MIG400iCCCV - PARTS LIST AND EXPLODED VIEW

12
Parts List and Exploded view
No.
QTY
ESAB CODE NO
ESAB ITEM DESCRIPTION
1
1
0800660001
MAIN TRANSFORMER(MIG400iCCCV)
2
1
0800660002
FILTER CAPACITOR(MIG400iCCCV)
3
1
0800660003
RES'NCE INDUCTANCE(MIG400iCCCV)
4
1
0800660004
MAIN CONTROL BRD(MIG400iCCCV)
5
1
0800660005
CONTROL TRANSF. 1(MIG400iCCCV)
6
1
0800660006
PWM CONTROL WIRE(MIG400iCCCV)
7
1
0800660007
CONTROL TRANSF. 2(MIG400iCCCV)
8
1
0800660008
TOP PANEL(MIG400iCCCV)
9
2
0800660009
TOP PANEL STRENGT RIB(MIG400iCCCV)
10
1
0800660010
COMMON MODE CHOKE(MIG400iCCCV)
11
1
0800660011
PWM AND DRIVE BRD(MIG400iCCCV)
12
1
0800660012
CUR&VOLT FEEDBACK WIRE(MIG400iCCCV)
13
1
0800660013
MOUNTING PANEL(MIG400iCCCV)
14
1
0800660014
CUR.INDUCTANCE SUPP(MIG400iCCCV)
15
1
0800660015
CUR SAMPLING BRD(MIG400iCCCV)
16
1
0800660016
RADIATOR CONN.BRD(MIG400iCCCV)
17
1
0800660017
IGBT RADIATOR(MIG400iCCCV)
18
1
0800660018
BOTTOM PANEL(MIG400iCCCV)
19
1
0800660019
BACK PANEL(MIG400iCCCV)
20
1
0800660020
CABLE FIXED HEAD(MIG400iCCCV)
21
1
0800660021
POWER CORD(MIG400iCCCV)
22
1
0800660022
ELCB (MIG400iCCCV)
23
2
0800660023
SWITCH SUPPORT(MIG400iCCCV)
24
1
0800660024
TWO PIN SOCKET(MIG400iCCCV)
25
1
0800660025
FUSE SUPPORT(MIG400iCCCV)
27
1
0800660026
AXIAL FLOW FAN(MIG400iCCCV)
28
1
0800660027
RIGHT PANEL(MIG400iCCCV)
29
2
0800660028
WIND SCREEN(MIG400iCCCV)
30
2
0800660029
ABSORB CAPACITOR(MIG400iCCCV)
31
4
0800660030
IGBT BUSBAR(MIG400iCCCV)
32
1
0800660031
IGBT ABSORB CAP. SUPP(MIG400iCCCV)
33
1
0800660032
PRIMARY ABSORB BRD(MIG400iCCCV)
34
2
0800660033
FILTER INDUCTANCE(MIG400iCCCV)
35
2
0800660034
IGBT(MIG400iCCCV)
36
1
0800660035
3P RECTIF. BRIDGE(MIG400iCCCV)
37
1
0800660036
THERMORELAY(MIG400iCCCV)
38
1
0800660037
RADIATOR SUPPORT(MIG400iCCCV)
39
2
0800660038
FILTER CAPACITOR(MIG400iCCCV)
40
4
0800660039
POLY'LENE CAPACITOR(MIG400iCCCV)
41
1
0800660040
OUTPUT RADIATOR(MIG400iCCCV)
42
2
0800660041
OUTPUT FIXED BRD(MIG400iCCCV)
43
2
0800660042
EU TYP QUICK CONN.(MIG400iCCCV)
