ESAB MIG400iCCCV - RATING; INSTALLATION; MIG Application Installation Requirements; MMA Application Installation Requirements

5
RATING
RATING OF MIG400iCCCV INVERTER WELDING POWER SOURCE
CHARACTERISTICS
CONSTANT VOLTAGE/
CURRENT TYPE
Input:
SUPPLY VOLTAGE, PHASE & FREQUENCY
415V± 15%, 3Phase, 50 Hz, AC
MAXIMUM INPUT CURRENT
26.6 A
Output:
OUTPUT CURRENT RANGE
DC 40-400A
VOLTAGE RANGE
16-34 V DC
TYPE OF WELDING CURRENT CONTROL
STEPLESS
CLASS OF INSULATION
‘H’
COOLING
FORCED AIR COOLED
APPROX DIMENSION (LxWxH) IN MM
654 x 322 x 671
WEIGHT (APPROX)
50.5 KG.
INSTALLATION
The complete installation for MIG application should consist the following items:
Description
Type
Quantity
1.
Welding Power Source
MIG400iCCCV
1
2.
Wire feeder with
Interconnections, Wire
spool
MIG400i wire
feeder
1
3.
MIG Torch for MIG
1
4.
Earth cable with Clamp
1
5.
Heater - optional
110V A.C. for CO2
1
6.
GAS with regulator
1
The complete installation for MMA application should consist the following items:
Description
Type
Quantity
1.
Welding Power Source
MIG400iCCCV
1
2.
Welding Cable with
Electrode Holder.
1
3.
Earth cable with Clamp
1
