ESAB MobileFeed 201 AVS User Manual

3 TECHNICAL DATA
0558 012 630
- 8 -
© ESAB AB 2015
3 TECHNICAL DATA
NOTE!
The MobileFeed 201 AVS is not recommended for short circuiting transfer using
constant current power sources due to the limited short circuit current available
on constant current power sources.
MobileFeed 201 AVS
Wire feed speed 50 – 750 in/min (1.3 – 19.0 m/min)
Primary input (open circuit voltage or arc voltage) Not for use with AC power
Minimum 14.0 V DC
Maximum 100 V DC (113 V peak)
Standard spindle hub 2” (5.1 cm) ID
Standard spool 8” (20.3 cm) OD
Maximum welding current 320 A at 60 % duty cycle
250 A at 100 % duty cycle
Maximum gas inlet pressure 75 psi (5.2 Bar)
Wire diameters
Hard .030” (0.8 mm), .035” (0.9 mm),
.045” (1.2 mm), .052” (1.4 mm),
1/16” (1.6 mm)
Soft .035” (0.9 mm), 3/64” (1.2 mm),
1/16” (1.6 mm)
Cored .030” (0.8 mm), .035” (0.9 mm),
.045” (1.2 mm), .052” (1.4mm),
1/16” (1.6 mm), 5/64” (2.0 mm)
Motor type DC permanent magnet pre-lubricated, enclosed
Brake type (wire) Drag
Control Solid state
Feed system Push
On-Off switch Standard
Ramp start Standard
Height × Width × Length 14.50" × 7.375" × 18.50"
(368.3 × 187.3 × 470 mm)
Weight (with contactor, without spool) 28 lbs (12.7 kg)
Enclosure class IP23S
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration
by solid objects or water.
Equipment marked IP 23S is intended for indoor and outdoor use; however, should not be
operated in precipitation.
