5 OPERATION
0463 363 101
- 13 -
© ESAB AB 2019
WARNING!
Rotating parts can cause injury, take great care.
WARNING!
There is a risk of tipping if the wire feed unit is fitted with a counterbalance arm. Make
sure to install the stabilizer kit and secure the equipment, especially if used on an
uneven or sloping surface.
Recommended maximum current values for connection set cables
I
max
Cable area Cable length Note
450 A (60% duty cycle)
70 mm
2
2 - 35 m 19 pole
350 A (100% duty cycle)
550 A (60% duty cycle)
95 mm
2
2 - 35 m 19 pole
430 A (100% duty cycle)
450 A (60% duty cycle)
70 mm
2
2 - 35 m 19 pole, water
350 A (100% duty cycle)
550 A (60% duty cycle)
95 mm
2
2 - 35 m 19 pole, water
430 A (100% duty cycle)
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or
cut at a certain load without overloading. The duty cycle is valid for 40°C/104°F, or below.
