WEAR PARTS

0463 363 101

- 23 -

Item Ordering number Denomination Notes

HI 6 Washer Ø 16/5×1

HI 7 Screw M4×12

HI 8 Screw M6×12

HI 9 Washer Ø 16/8.4×1.5

HI 10 0469 838 001 Cover

HI 11 0458 722 880 Axle and Nut

HI 12 0459 441 880 Gear adapter

HI 13 0455 049 001 Inlet nozzle Ø 3mm for 0.6-1.6mm Fe, Ss, Al and cored wire

0460 007 001 Inlet nozzle Long-life for Fe, Ss and cored wire

HI 14 0458 999 001 Shaft

HI 15 Nut M10

HI 16 0458 748 002 Insulating

washer

HI 17 0458 748 001 Insulating

bushing

Item Ordering

number

Denomination Wire type Wire dimensions

HI 18 0156 602 001 Inlet nozzle Ø 16/5×1 Ø 2 mm plastic for 0.6 - 1.6 mm

Welding with aluminium wire

In order to weld with aluminium wire, U-shaped rollers, nozzles and liners for aluminium wire

must be used. It is recommended to use 3 m long welding torch for aluminium wire,

equipped with appropriate wear parts.
