16
1 3M-6850-00 4" Square Tube Plug (Pre-Installed) 1
2 1A-7686-02 Bottom Post 1
3 8S-6898-02 Top Post 1
4 901-28 3/8-16 Nylon Insert Locknut 14
5 3M-6883-00 1-1/4" OD Plastic Washer 8
6 8S-6630-01 Upper Board Arm 2
7 1B-6483-10 3/8-16 X 7.5" Hex Bolt-Grade 5 1
8 3M-6269-00 1/4" Spacer 2
9 3M-6548-00 1 X 2 Tube Plug 8
10 8S-6657-00 Stop Spacer 2
11 1A-6331-01 Lower Board Arm 1
12 NOT USED
13 3M-6467-00 Actuator Cap 1
14 8S-6658-00 Pivot Tube 1
15 3M-6542-00 Actuator Sleeve 1
16 4A-6605-00 Actuator 1
17 4L-7501-00 Height Decal 1
18 701-50 3/8 STD Washer 18
19 1B-6486-10 1/2-13 X 1-1/2" Hex Bolt 1
20 2B-6093-00 1/2 Flat Washer 2
21 2B-6095-00 1/2-13 Nylon Insert Locknut 1
22 1B-6484-10 3/8-16 X 7" Hex Bolt-Grade 5 3
23 6A-7625-00 Backboard Assembly-54x33” Glass 1
24 1B-6195-00 3/8-16 X 2.75" Hex Bolt 4
Key# Part # Description Qty. Key# Part # Description Qty.
25 1B-6485-10 2
26 2B-6114-00 4
27
28 6A-6374-00 1
29
30 2S-6795-01 2
31 Not Used
32 2S-6427-00 1
33 1B-6788-00 4
34 3M-6469-00 4
35 2B-6097-00 12
36 2B-6099-00 4
37 2B-6098-01 8
38 2S-6453-00 1
39 2B-6112-00 4
40 1S-6167-00 4
41 7B-6255-00 1
42 4A-6606-00 1
43 2L-7197-01 1
44 3M-6580-01 1
45 3M-6581-01 1
46 Not Used
47 3F-6010-00 1
48
49 1B-6782-00 4
50 Not Used
77 1B-6821-00 10
2L-7197-03
- BACKBOARD -
Items needed to clean backboard:
- 100% cotton soft cloth, (only)
- Glass Cleaner
Clean backboard using a 100% Cotton soft cloth and glass cleaner. Clean glass as you would household windows. Strong cleansers will damage
backboard and void warranty.
– RIM –
HANGING ON THE RIM WILL VOID YOUR WARRANTY. Rims are not warranted for any defects other than workmanship. Torn back plates,
damaged springs, bent rings, damaged eye bolts, and torn or distorted rim supports result from hanging on the rim and are not warranted.
The goal should not be cranked under 7-1/2' or over 10'. Adjustments of the goal should be done under adult supervision.
When attempting slam dunk activity you should always wear a mouth guard to avoid dental injury.
SILVERBACK CARE INFORMATION
To ensure ease of operation, lubricate all pivot points at least every 6 months or as needed with a good lubricant such as WD-40.
Inspect your pole periodically, if rust should appear
, remove loose paint, sand lightly, primer and paint with exterior flat matte finish
enamel paint.
– –MAINTENANCE
– – RUST
1
(Pre-Installed)
(Pre-Installed)
(Pre-Installed)
B5401 REPLACEMENT PARTS LIST
3/8-16 X 5" Hex Bolt
3/8 Flat Washer
Goal Assembly
Goal Spacer Plate (Pre-Installed)
Post Ear
Rim Cover Plate
#8 x 1/2 Thread Forming Scr. 5/8
Thread Protector
5/8-11 Hex Nut
5/8 Split Lockwasher
5/8 SAE FLAT WSHR ZNC
Anchor T. emplate
5/8-11 X 14 "J" Bolt
#3 X 30" Rebar
Pull Pin
Actuator Handle
This Manual
48" Board Pad Right
48" Board Pad Left
Net
3/8-16 x 1 3/4" Carriage Bolt
Self Tapping Screw-#10 x 1 1/8"
Not Used
