ESP Aperta APDSPXMW - Table of Contents

2
Contents
System Components ............................................................... 3
Installation ....................................................................... 3
Door Station Wiring Example 1 ...................................................... 4
Door Station Wiring Example 2 ...................................................... 5
Lock Connection Example 1 ......................................................... 6
Lock Connection Example 2 ......................................................... 7
Door Station Programming Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Door Station Keypad User Guide ................................................... 10
Installer’s troubleshooting Guide .................................................. 13
Optional Accessories ............................................................ 13
System Cabling
All system cabling (excluding mains 240vAC supply) has been tested with
Cat5E UTP PVC cable.
Part Number - A8NFORCE5EUTP
Find this product online:
elandcables.com | Cables & Accessories | LAN Cable | Cat 5E UTP PVC
Cable
