GuardCam LED Motion Light with Video Camera
Step 1 – Insert/remove SD card
 Unscrew the waterproofed cover using provided Allen key, then insert the SD card
until it automatically locks into place.
 If you need to remove the SD card, please press OFF button and take it out within
30 seconds.
 When LED light turns green, meaning SD card is being read, do not remove SD
card or data may be lost.
 To remove SD card, push in SD card to eject. Once to unlock then pull out.
High intensity LED
45º
45º
35º
45º
45º
50º
Waterproof cover
3 mode selection
Camera lens
PIR lens
Low battery indicator
Floodlight Cover
Fig. 1
4
