Bench-top type temperature(humidity) chamber Installation guide
14 ESPEC CORP.
7. Power supply work
Primary power supply requirements
Notice
・ Always take care to comply with your national regulations for power supply
installations. If a drainage pit is not located near the chamber, drain in a container.
・ External power supply cables shall be of approved type and in compliance
with IEC/EN60227 or IEC/EN60245 or any other applicable national regulation.

Prepare the power supply and power cable satisfying the following requirements.
◆
Note
◆
The following table shows the supply voltage ranges for power supply voltage fluctuation
that the chamber can operate in, but keep the range within ±5% as much as possible.
Selection
Power
supply
100V AC 1Ø
2W 50/60Hz
115V AC 1Ø
2W 60Hz
200V AC 1Ø
2W 50/60Hz
220V AC 1Ø
2W 50/60Hz
230V AC 1Ø
2W 50Hz
Power supply
voltage
fluctuation
90V to 110V 103V to 126V 190V to 220V 198V to 242V 219V to 241V
(±10%) (±10%)
(-5%、+10%)
(±10%) (±5%)

Maximum current per voltage specification, minimum cable diameter and fuse capacity
must be as below. Prepare a power supply that meets with chamber power supply voltage
specifications.
Power supply voltage (V AC) Max. current (A)
Min. power
cable size
(mm
2
)
Fuse capacity
(A)
SH-222,242
100V 50Hz/60Hz 1Ø 2W 11.3 (11.8) 2 15
115V 60Hz 1Ø 2W 12.8 (13.3) 14AWG 15
220V 50Hz/60Hz 1Ø2W 5.4 (5.7) 0.75 10
230V 50Hz 1Ø2W 5.3 (5.6) 0.75 10
SU-222,242
100V 50Hz/60Hz 1Ø 2W 9.3 (9.8) 2 15
115V 60Hz 1Ø2W 11.0 (11.5) 14AWG 15
220V 50Hz/60Hz 1Ø2W 4.5 (4.8) 0.75 10
230V 50Hz 1Ø2W 4.4 (4.7) 0.75 10
SH/SU-262
100V 50Hz/60Hz 1Ø 2W 15.0 (16.0) 2 20
200V 50Hz/60Hz 1Ø 2W 14.0 (14.5) 2 15
220V 50Hz/60Hz 1Ø 2W 13.5 (14.0) 1.5 15
230V 50Hz 1Ø 2W 13.5 (14.0) 1.5 15
