ESPEC SU 242 - Page 8

Bench-top type temperature(humidity) chamber Installation guide
6 ESPEC CORP.
Model
Weight
(kg)
Outside dimensions (mm)
Center of gravity position (cm)
* Distance from reference
point
W H D W H D
SU
222/242 73 440
625
696
[747]
23 30 39
242-5 101 440
625
786
[834]
22 30 47
262 100 440
625
786
[834]
22 29 47
642/662 123 540
665
921
[943]
27 33 54
SH
222/242 78 440 690
696
[747]
23 34 39
242-5 106 440 690
786
[834]
22 34 47
262 105 440 690
786
[834]
22 34 46
642/662 130 540 730
921
[943]
27 37 54
* Reference point for center of gravity: Top left corner of the chamber door
* Dimensions in brackets "[ ]" include protrusions (instrumentation frame, condenser fan motor, and
cover for compressor terminals).
* Protrusions (instrumentation frame, condenser fan motor, and cover for compressor terminals) are
not taken into account in determining these center of gravity positions.
* The center of gravity position varies when options are included.

Installation condition
Install the chamber indoors in a place that satisfies the below conditions.
Flat place to withstand the weight of the chamber. (Weight of one chamber is as
follows.)
Model
SH SU SH SU SH SU SH SU
222,242 222,242 262 262 642,662 642,662 242-5 242-5
100V AC 78 73
105 100 130 123 106 101
Except
100V AC
83 78
With
viewing
window
(option)
89 84 111 106 137 130 112 107
(kg)
