12
Names and functions
(1) (3) (4) (10)
(2) (5) (6) (7) (8) (9)
No Name Function
(1) Power switch Power switch of main unit
(2)
Liquid crystal display /
operation section
Status display and change of setting can be
implemented from touch panel liquid crystal display
(3) Dust tray
Removable tray for collecting the dust removed from
frost surface
(4) Upper cover
Cover to be opened when accessing the inside of
device. Ink ribbon and slide glass are set from here.
(5) Power connector Insert the jack from AC adapter.
(6) LAN connector Connector of wireless LAN
(7) USB connector USB connector
(8) Wireless LAN antenna Antenna for wireless LAN
(9) USB A connector
Connect the USB memory at the connection of optional
barcode scanner or download of firmware
(10)
Cable clamp
Clamp that prevents disconnection of power supply and
I/F cable
