ESS GPS-5 OWNER’S MANUAL
GPS-5 service parts
TANK ORIFICE ESS PART
UNIT STYLE SIZE NUMBER PART NUMBER
XT 3 GALLON TANK #20 765
XT 1 QUART BOTTLE #40 766
GPS 4 GALLON TANK #30 1755
EPS 4 GALLON TANK #30 1755
TRG 4 GALLON TANK #30 1755
J SERIES 15 GALLON TANK #30 1755
BP-2.5 2.5 GALLON TANK #59 4350
BP-4 4 GALLON TANK #59 4350
Flow disk chart
Note: Use of a ow disk is crucial to the operation of the spray
gun. If the wrong size ow disk, or no ow disk is used, then the
spray gun will not spray or charge eciently
ITEM ESS QUANTITY
NUMBER PART NUMBER DESCRIPTION ORDERED
1 AP-5795 Hood 1
2 NC 5764 Nozzle Cover 1
3 5771 O-Ring, Internal 1
4 AP-5694 Teon Ring 1
5 NB-5983 Nozzle Body, Greenhouse 1
Note: Must Send Spray Gun In For Repair
6 5770 O-Ring, External 1
7 3731 Repair Kit, Trigger 1
8 767 Cap, Flow Regulator 1
9 768 Adapter, ⁄”-27 FPT 1
10 1755 Orice Disk (Flow Disk) 1
11 437 Strainer, #50 Mesh 1
12 770 Body, ⁄”-27 FPT, Greenhouse 1
13 227 Filter, Air, In-Line 1
14 231 Repair Kit, Air Filter
(NOTE: for models manufactured pre March 2009) 1
15 4512 Battery, Alkaline, 9 V 2
16 118 Battery Cover, Spray Gun Shell 1
17 316 Screw, #6-32 × ⁄” Long, Phillips, SS 2
18 239 QC Plug, ⁄”, ⁄” MPT, Brass (Spray Gun Liquid) 1
19 AS-1748 Spray Gun Leader Assembly, Liquid 1
20 240 QC Plug, ¼”, ¼” MPT, Brass (Spray Gun) 1
21 AS-1749 Spray Gun Leader Assembly, Air 1
22 6518 Trigger Pawl 1
23 4430 Battery Charger 1
Spray gun
