33
ESS GPS-5 OWNER’S MANUAL
ITEM ESS PART QUANTITY
NUMBER NUMBER DESCRIPTION ORDERED
1 29 BELT GUARD 1
2 2683 SCREW, #12 x 7/8” LONG, SELF-DRILLING, TEK, SS 4
3 6217 ¼” F/W 4
5 1925 BRACKET, BELT GUARD 1
7 17202 V-BELT, A45, ZP 1
8 17203 SHEAVE, BK-28, ZP 1
9 35 KEY 1
10 75 HEX NUT, 5/16”-18, ZP 13
11 73 LOCKWASHER, 5/16”, ZP 13
12 74 FLATWASHER, 5/16”, ZP 17
13 27 ENGINE, 5 HP, BRIGGS & STRATTON 1
14 1907 HHCS, 5/16”-18 x 2” LONG, ALL-THREAD, ZP 5
15 244 GPS ENGINE BACK-UP PLATE 1
16 242 RADIATOR, 5/8” DIA TUBE X 6 PASS 1
17 1152 ADAPTER, 3/8” FPT X 1/2” SWEAT, COPPER 3
18 1904 COMPRESSOR 1
23 1809 ADAPTOR, COMPRESSION, 3/8” MPT × ½” TUBE 1
24 1905 COPPER COOLING COIL 1
25 72 HHCS, 5/16”-18 x 1 1/2” LONG, G5, ZP 4
26 AW1815 MAIN FRAME WELDMENT, EPS/GPS 1
27 1903 GROUND CHAIN 1
39 1914 HOSE ASSY, EPS/GPS, AIR, TEE TO REEL 1
40 748 TIRE 4
41 4 SHAFT COLLAR, 5/8” ID, 1/2” WIDE 8
43 247 HEX NUT, 1/4”-20, ZP 2
44 70 LOCKWASHER, 1/4”, ZP 2
45 51 TRIM RING 1
46 1234 TEE, 1/4” NPT, STREET, BRASS 1
48 67 ELL, 1/8” NPT, STREET, 90 DEG, BRASS 2
49 440 GAUGE, PRESSURE, 1/8” NPT, 0-30 PSI 1
50 62 POP-OFF VALVE, 1/4” MPT 1
51 1182 REGULATOR, AIR 1/4” NPT 1
53 PP1575 HOSE, 1/4” ID, FABRIC COV, 1/4” MPT x 1/4” MPT, 20” LONG 1
54 111 COUPLING, 1/4” NPT, HEX, BRASS 1
55 1149 CHECK VALVE, 1/4” NPT 1
56 1067 REDUCING NIPPLE 1/4” MPT x 1/8” MPT, BRASS 1
57 248 TANK INLET QUICK CONNECT SOCKET 1
58 833 HANDLE BALL, BLACK PLASTIC 1
59 1745 STUD, ALL THREAD, 3/8”-16 x 1 1/2” LONG, STEEL 1
60 1916 HANDLE, HOSE REEL 1
61 586 LOCK NUT, STOVER, TOP, 3/8”-16,ZP 1
62 73 LOCKWASHER,5/16, ZP 2
63 71 HHCS, 5/16”-18 x 1” LONG, ZP 1
64 1911 HOSE REEL 1
65 1738 CARRIAGE BOLT, 1/4” -20 x 1 1/2” LONG, ZP 2
66 1912 HOSE ASSY, EPS/GPS/J, LIQUID, TANK TO REEL 1
67 181 WIRE TIE, NYLON, 4” LONG 4
68 156 ELL, 1/4” NPT, STREET, 90 DEG, BRASS 1
69 450 TANK OUTLET QUICK CONNECT SOCKET 1
Service parts
GPS-5
