ACTIVE POWER CONTROLLER
PRECAUTIONS
The installation, configuration, commissioning and
maintenance of the power unit should only be
carried out by personnel qualified and trained to work with
low voltage electrical equipment in an industrial environment.
ATTENTION
SAFETY
EARTH
Controller must be installed in electrical cabinets correctly
fan-cooled to ensure that condensation and pollution are
excluded.
The units are designed to be used at an ambient
temperature less than 40°C and leave a minimum gap of
5cm between two units placed side by side. Excessive
overheating of the controller may lead to incorrect operation
of the unit. And this may in turn cause damage to the
components.
Overheating at overload driving can be produced.
Work after cool enough in case of do checking, full
equipment.
DANGER
AND
ATTENTION
DANGER
Precautions and description
Safety symbols
Item
This symbol is marking contents about danger (electric
shock, electrical impact etc..) that can happen by electric
problem.
This product of when repairs, shut off main power of
controller, controlled source and cooling - fan's power
certainly, and works after is discharged perfectly measuring
residual voltage in controller load side according to load's
kind
This symbol is marking contents of mistake or failure that can
happen serious missing incorrect operation or on sequences
for the installation of the power unit.
Please observe guideline of this manual certainly.
Before any connection or disconnection, ensure that
power and control cables or leads are isolated from
voltage sources.
For safety reasons, the safety earthing cable must be
connected before any other connection is made during
wiring and it should be the last cable to be disconnected.
The safety earth is connected to the screw located on
the terminal block of the PCB.:
