APC-TF Series Model identification
①
Application
▷ APC : ACTIVE POWER CONTROLLER
▷ MSC : MOTOR SOFT-START CONTROLLER
②
Phase
▷ S : SINGLE-PHASE AC
▷ T : THREE-PHASE AC
⑥
Controls
▷ P : PHASE-ANGLE CONTROL
▷ Z :
Fixed time base
ZERO-CROSS CONTROL
④
Line-to-line voltage
▷ 2 : 220V AC
▷ 3 : 380V AC
▷ 4 : 440V AC
▷ 6 : 690V AC
⑤
Nominal current (per phase)
▷ 30A/40A/55A/70A/90A/110A/130A/160A/200A/250A/300A/400A/500A
⑦
User option
③
DISPLAY type of outside panel
▷ N : LED information display
▷ F : FND, 7-segment
▷ L : LCD
• APC-TF Series Model identification
APC – TF3 – 100 – P -
① ②③④ ⑤ ⑥ ⑦

EST APC-TF Series Specifications

General

Brand	EST
Model	APC-TF Series
Category	Controller
Language	English
