APC-TF Series TECHNICAL SPECIFICATION
The Model APC-TF Series is a new generation SCR Active Power Controllers for use with resistive,
inductive loads. This unit features the optimum conditions heatsinks with remote analog set-point
value for precise control. Basic include diagnostic load failure detection, a wide scope fault
detection. Fault indicates when a shorted device or an open load is detected.
• APC-TF Series TECHNICAL SPECIFICATION
State items Technical Specification Remarks
Line-to-line voltage
AC 220V / 380V / 440V ±10%
Nominal current
(per phase)
35A – 500A
Less then
70%
External control signal
Analogue voltage 0 to 5V or 1 to 5V;
current 0 to 20mA or 4 to 20mA
Contact (ON/OFF mode)
Potentiometer for manual set-point
(5 V supply available).
Application
Heater control
Controls
• PHASE ANGLE FIRED
• ZERO VOLTAGE SWITCHED ( ZERO VOLTAGE
CROSSING)
• ON/OFF CONTROL
Loads
Inductive load , Resistive load with a low -
temperature coefficient or short-wave infrared
elements
Supply frequency
50Hz and 60Hz (±2Hz) automatic selection
Soft control
Soft Start / Stop , Soft up / down 0 – 10 sec
Output range
0 – 97% of the input line-to-line voltage
Ambient
Temperature
Operating : 0 to +40 ℃(+32 to +104 ℉)
Storage : -40 to +80 ℃(-40 to +176 ℉)
Insulation (1 min test)
2000Vac between power and earth and 3600Vac
between power and control
Cooling
Natural convection for less then 70A ratings
Permanent fan-cooling for more then 90A rating
Alarm functions
- Over current trip
- Heatsinks over temperature detect
- Load failure detect
- Fuse failure detect
- SCR failure detect
